Introduction
-
Features:
1. One-button opening, fool-like operation;
2. Suitable for a variety of sizes of cartons, quick and easy to adjust.
3. The high-strength grip PVC belt is used to drive the double side of the carton, and the transmission is stable;
4. The tape sealing is flat, firm, standardized, beautiful, will not tear the box, and has high efficiency;
5. Adopt domestic high-quality micro geared motor, stable operation.
6. Equipped with a number of automatic safety protection functions, so that the production is safer and the sealing is more efficient.
7. It can be operated as a stand-alone machine or used in conjunction with an automated assembly line.
8. The product life is more than 10 years, and the carton damage rate is less than two thousandths.Technical Parameters:
Name GT-FX210 Automatic Carton Sealer Applicable Products L200mm~600mm；W200mm~500mm；H200mm~500mm Operating Principle Automatic folding cover, machine automatic tape (up and down at the same time), can work continuously Capacity 15 cartons/min Transmission form High grip belt drive on both sides Dimension 1750mm × 960mm × 1580mm Weight 240kg Material Carbon steel surface spraying Table height 500~780mm (casters adjustable) Types of tape BOPP, kraft paper, PVC self-adhesive tape Tape width 48mm，60mm Air pressure & consumption 6-7 Bar,50NL/min Power supply 220V，50Hz，0.18kW
